Atlas air compressorHow to implement Data Acquisition and monitoring?

One Related Introduction

Generally speaking, the current mainstream communication design schemes are basically realized throughProtocolGatewayMK5, etc. officially provided by Atlas.

The upper computer or PLC end is usually connected through Modbus Protocol orSiemens DP ProtocolCommunicate with MK5, which processes and translates data to communicate with the air compressor equipment controller, mostly using CAN.

II Implementation method

The first is through the purchase of Atlas CommunicationsGateway. The advantage is that it is the same brand as the air compressor and can be purchased from Atlas air compressor suppliers at prices ranging from RMB 8-12000. The specific price depends on the supplier channels. The disadvantage is that there are link restrictions and debugging is complex, requiring suppliers to debug and configure before use.

The second method is to use theProtocollibrary orProtocolprovided by third-party manufacturers. The advantages are cheap price, short delivery time, and good product experience, but the disadvantage is that there is no brand effect. For high-end users who are not short of money and require no mistakes, try not to choose third-party manufacturer products. Our IoT company is a third-party manufacturer.

Atlas air compressorCANProtocolIt is a serial bus Protocol used for communication between devices, widely used in the field of industrial automation, with high reliability and Real-time performance. TheProtocolis mainly used in Atlas air compressor to realize cluster control, parameter monitoring and fault diagnosis of multiple equipment. 1 2ProtocolFeatures and functions: The application of CANProtocolin Atlas air compressors is mainly reflected in the following aspects: equipment integration and cluster control: support multiple air compressors to connect in series through the CAN bus to achieve centralized monitoring and automatic scheduling, for example, throughProtocolconversionGatewayand integration with PLC systems (such as Siemens 1200 series), automatically start and stop the equipment according to the pipe network pressure, improve the pressure control accuracy and reduce energy consumption. Data exchange and Remote Monitoring: through intelligent controllers (such asElektronikon）Realize the upload of parameters such as operating status, exhaust pressure, and fault codes, and be compatible with Modbus's extended remote control function. Industrial environment adaptability: using shielded cable connection, strong anti electromagnetic interference ability, suitable for complex workshop environments. ‌

Typical application scenarios: In practical projects, CAN Protocol is commonly used for cluster management of air compressors in industries such as mechanical manufacturing and energy, for example, throughProfiNetConvert CAN Gateway to achieve seamless integration with the upper computer system, complete data mapping and instruction conversion, and ensure accurate execution of control instructions (such as start stop and pressure setting). 1 Configuration and compatibility: The CANProtocolof Atlas air compressor is usually preset with standard parameters (such as baud rate of 500kbps, standard frame format), which should be consistent withGatewayor PLC configuration to avoid communication failures; Meanwhile, its intelligent controller supports multiProtocolcompatibility, making it easy to integrate with different industrial networks such as ProfiNet and Modbus
