Example of PLC Data Acquisition Workshop Networking Point Representation in Chemical Plant

As a professional provider of IoT data acquisition solutions and an expert in industrial IoT data acquisition, the editor of Shanghai Data Acquisition IOT Technology Co., Ltd， (daq-iot) hereby presents the following introduction, and sincerely welcomes discussions and exchanges. Supported Communication Interfaces: CAN, RS485, Mbus, 4–20mA, Profibus, CC-Link, HART, digital I/O, etc. Industrial Protocols: Modbus RTU/TCP, HJ212, IEC104, DLT645, DLMS, IEC61850, MQTT, etc. Mail:export@daq-iot.com

Long Xiang gives Celanese


Gateway Number Name CMX Register Address Gateway Register Address Gateway Modbus Register Address Conversion Modbus Node Address Gateway IP Address

Accumulated high level of acetic acid flow ELPRO: O.Data [0] N9:0 40001 10000 7 (10 #) 198.186.202.241

Accumulated low acetic acid flow ELPRO: O.Data [1] N9:1 40002

Acetic acid flow instantaneous ELPRO: O.Data [2] N9:2 40003/10

Acetic acid pressure ELPRO: O.Data [3] N9:3 40004/10

Acetic acid temperature ELPRO: O.Data [4] N9:4 40005/10

Accumulated high methanol flow ELPRO: O.Data [5] N9:5 40006 10000

Accumulated low methanol flow ELPRO: O.Data [6] N9:6 40007

Methanol flow instantaneous ELPRO: O.Data [7] N9:7 40008/10

Methanol pressure ELPRO: O.Data [8] N9:8 40009/10

Methanol temperature ELPRO: O.Data [9] N9: 9 40010/10

Acetic acid tank 1 liquid level ELPRO: O.Data [10] N9:10 40011/10

Acetic acid tank level ELPRO: O.Data [11] N9:11 40012/10

Acetic acid tank No. 3 liquid level ELPRO: O.Data [12] N9:12 40013/10

Liquid level of methanol tank No.1 ELPRO: O.Data [13] N9:13 40014/10

Methanol tank level ELPRO: O.Data [14] N9:14 40015/10

Liquid level of methanol tank 3 ELPRO: O.Data [15] N9:15 40016/10

2 VAM Cumulative Flow High Level ELPRO: O.Data [16] N9:0 40001 6 198.186.202.242

VAM Cumulative Flow Low ELPRO: O.Data [17] N9:1 40002

VAM Instantaneous Flow ELPRO: O.Data [18] N9:2 40003

VAM Pressure ELPRO: O.Data [19] N9:3 40004/10

VAM Temperature ELPRO: O.Data [20] N9:4 40005/10

AC20- Cumulative high traffic ELPRO: O.Data [21] N9:5 40006

AC20- Accumulated low traffic ELPRO: O.Data [22] N9:6 40007

AC20 instantaneous flow ELPRO: O.Data [23] N9:7 40008/10

AC20 Pressure ELPRO: O.Data [24] N9:8 40009/10

AC20 Temperature ELPRO: O.Data [25] N9:9 40010/10

VAM liquid level 1 ELPRO: O.Data [26] N9:10 40011/10

VAM liquid level 2 ELPRO: O.Data [27] N9:11 40012/10

AC20- Level 1 ELPRO: O.Data [28] N9:12 40013/10

AC20- Level 2 ELPRO: O.Data [29] N9:13 40014/10

VAM liquid level 3 ELPRO: O.Data [30] N9:14 40015/10

VAM liquid level 4 ELPRO: O.Data [31] N9:15 40016/10

3 C2H4- Cumulative high traffic ELPRO: O.Data [32] N9:0 40001 8 (15 #) 198.186.202.243

C2H4- Accumulated low traffic ELPRO: O.Data [33] N9:1 40002

C2H4- Instantaneous flow ELPRO: O.Data [34] N9:2 40003/10

C2H4- Pressure ELPRO: O.Data [35] N9:3 40004/10

C2H4- Temperature ELPRO: O.Data [36] N9:4 40005/10

C2H4_Level ELPRO: O.Data [37] N9:5 40006/10

C2H4_Level ELPRO: O.Data [38] N9:6 40007/10

ELPRO:O.Data[39] N9:7 40008

2 (New) EtOH instantaneous flow ELPRO: O.Data [40] N9:36 40037 6 (New 13 #) 198.186.202.242

EtOH cumulative flow high ELPRO: O.Data [41] N9:37 40038

EtOH cumulative flow low ELPRO: O.Data [42] N9:38 40039

EtAC instantaneous flow ELPRO: O.Data [43] N9:39 40040

EtAC cumulative flow high ELPRO: O.Data [44] N9:40 40041

EtAC cumulative traffic low ELPRO: O.Data [45] N9:41 40042

EtAC liquid level A ELPRO: O.Data [46] N9:42 40043

EtAC liquid level B ELPRO: O.Data [47] N9:43 40044

3 (New) EtOH liquid level A ELPRO: O.Data [48] N9:18 40019 8 (New) 198.186.202.243

EtOH liquid level B ELPRO: O.Data [49] N9:19 40020

Seranis to Long Xiang

Number Name CMX Register Address Gateway Register Address Gateway MODBUS Address Modbus Node Address Gateway IP Address

1. Cumulative high acetic acid flow ELPRO: I. Data [0] N9:16 40017/10000 rounded up 7 198.186.202.241

Acetic acid flow cumulative low ELPRO: I. Data [1] N9:17 40018- high

Acetic acid flow instantaneous ELPRO: I. Data [2] N9:18 40019 * 10

Acetic acid pressure ELPRO: I. Data [3] N9:19 40020 * 10

Acetic acid temperature ELPRO: I. Data [4] N9:20 40021 * 10

Accumulated high methanol flow ELPRO: I. Data [5] N9:21 40022/10000 rounded up

Accumulated low methanol flow ELPRO: I. Data [6] N9:22 40023- High level

Methanol flow instantaneous ELPRO: I. Data [7] N9:23 40024 * 10

Methanol pressure ELPRO: I. Data [8] N9:24 40025 * 10

Methanol temperature ELPRO: I. Data [9] N9:25 40026 * 10

2 VAM - Cumulative flow high ELPRO: I. Data [10] N9:16 40017/10000 rounded 6 198.186.202.242

VAM - Cumulative Flow Low ELPRO: I. Data [11] N9:17 40018- High

VAM Instantaneous Flow ELPRO: I. Data [12] N9:18 40019

VAM Pressure ELPRO: I. Data [13] N9:19 40020

VAM Temperature ELPRO: I. Data [14] N9:20 40021

AC20- Cumulative high traffic ELPRO: I. Data [15] N9:21 40022/10000 rounded up

AC20- Cumulative Flow Low ELPRO: I. Data [16] N9:22 40023- High

AC20 Instantaneous Flow ELPRO: I. Data [17] N9:23 40024

AC20 Pressure ELPRO: I. Data [18] N9:24 40025

AC20 Temperature ELPRO: I. Data [19] N9:25 40026

3 C2H4- Cumulative high traffic ELPRO: I. Data [20] N9:8 40009/10000 rounded up 8 198.186.202.243

C2H4- Accumulated traffic low ELPRO: I. Data [21] N9:9 40010- High

C2H4 Instantaneous Flow ELPRO: I. Data [22] N9:10 40011

C2H4 Pressure ELPRO: I. Data [23] N9:11 40012

C2H4- Temperature ELPRO: I. Data [24] N9:12 40013

C2H4 Liquid Level ELPRO: I. Data [25] N9:13 40014

2 (New) EtOH instantaneous flow ELPRO: I. Data [26] N9:26 40027 6 (New) 198.186.202.242

EtOH cumulative flow high ELPRO: I. Data [27] N9:27 40028/10000 rounded up

EtOH Cumulative Flow Low ELPRO: I. Data [28] N9:28 40029- High

EtAC instantaneous flow ELPRO: I. Data [29] N9:29 40030

EtAC cumulative flow high ELPRO: I. Data [30] N9:30 40031/10000 rounded up

EtAC Cumulative Flow Low ELPRO: I. Data [31] N9:31 40032- High

Backup ELPRO: I. Data [32] N9:32 40033

Backup ELPRO: I. Data [33] N9:33 40034

Backup ELPRO: I. Data [34] N9:34 40035

Backup ELPRO: I. Data [35] N9:35 40036

Explanation: 1. Communication adoptsModbus RTUProtocol RS485 electrical interface baud rate 4800 data bits 8 stop bits 1 no parity check

2. The CMX IP address is 198.186.202.102

Blue font added on April 9, 2013
