Factory Sewage Treatment Station - Environmental Protection Online Monitoring System - PH Water Flow COD Pollutant Treatment Equipment and Facilities Operation Status Data Acquisition Gateway

As a professional provider of IoT data acquisition solutions and an expert in industrial IoT data acquisition, the editor of Shanghai Data Acquisition IOT Technology Co., Ltd， (daq-iot) hereby presents the following introduction, and sincerely welcomes discussions and exchanges. Supported Communication Interfaces: CAN, RS485, Mbus, 4–20mA, Profibus, CC-Link, HART, digital I/O, etc. Industrial Protocols: Modbus RTU/TCP, HJ212, IEC104, DLT645, DLMS, IEC61850, MQTT, etc. Mail:export@daq-iot.com

asIoTData Acquisitionsolution professional provider, industrial Data Acquisition expert (professional account), and data acquisition IoT editor daq iot would like to introduce the following content here and sincerely welcome everyone to discuss and exchange ideas.

As a professional internet of things data acquisition solutions provider, industrial data acquisition experts (professional households), digital internet of things editor daq - iot here to do the following introduction, and sincerely welcome everyone to discuss and exchange.

Water flow collection Sensor "1. IntegratedElectromagnetic FlowmeterElectrode Material: Stainless Steel-316L;

2. Working temperature: -20~80 ℃;

3. Output signal: 4-20 mA.

4. Power supply method: battery power supply or wired power supply. If battery power is used, the battery can work normally for at least 3 years.

5. Error accuracy ± 1% "17 (including two DN40; Eight DN50; One DN80; Five DN100; DN200 one) "1. Inlet flow rate of fire water tank

2. Sewage treatment plant“

Sewage flow meter "1. Communication method: wireless, such as 5G/4G/wifi, etc;

2. Power supply method: battery power supply or wired power supply. If battery power is used, the battery can work normally for at least 3 years.

3. Support monitoring of sewage discharge Real-time;

4. Working temperature: -20 ℃ to 55 ℃;

★ 5. Error accuracy not less than ± 1%

6. Support on-site display ofReal-timetraffic and cumulative traffic. 1 (DN50) sewage discharge outlet: Factory sewage treatment station, power line 20 meters.

Multi function watt hour meter 1. Communication method: wireless, such as 5G/4G/wifi, etc;

2. Power supply method: battery power supply or wired power supply. If battery power is used, the battery can work normally for at least 3 years;

3. Working temperature: -10~60 ℃;

4. Function: Over temperature alarm for upper and lower terminals; Phase loss alarm, three-phase imbalance alarm; Overvoltage and undervoltage alarm; Leakage current protection. 20 units "1. Operating temperature: Alarm when exceeding 80 ℃.

2. Voltage deviation ± 10% alarm.

3. Remaining current of 10mA or 30mA.

4. Phase Loss Alarm "Electrical Fire Alarm Detection: Purchase 20 multifunctional energy meters to collect data on operating temperature, current and voltage, residual current, Real-time power, and fault status of high-power distribution cabinets. The collected fields include but are not limited to information such as occurrence time, location, signal type, signal value, alarm content, etc

Electric well temperature Sensor 1. Support high temperature alarm, temperature alarm threshold can be configured according to requirements, with a configuration range of 54 ℃ to 70 ℃;

2. Communication method: wireless, such as 5G/4G/wifi, etc;

3. Equipped with a built-in speaker and microphone, the alarm signal can be transmitted to the control center through the platform;

4. Support high brightness three color indicator lights and alarm voice prompts. 20 units

new purchaseTemperature and humidity information Sensor 1. The device must include at least Sensor and Gateway;

2. Communication method: wireless, such as 5G/4G/wifi, etc;

3. Power supply method: battery power supply or wired power supply. If battery power is used, the battery can work normally for at least 3 years;

4. Accuracy temperature: ± 0.3 ℃ (25 ℃); Humidity: ± 2% RH (25 ℃);

5. Working temperature: -10~50 ℃;

6. Protection level: IP65. 47 units with alarm function

PH detection equipment 1. Support high-definition image output of no less than 4 million;

2. Communication method: wireless, such as 5G/4G/wifi, etc;

3. Support pH value detection, range: 0-14.00pH;

4. Easy to sink or install in pipelines and tanks;

5. The alarm linkage includes white light flashing alarm and sound alarm, and the alarm signal can be transmitted to the control center through the platform; Install one new pH detection device for each of the eight water tanks on the rooftop of the eight silk processing plants to detect the pH value in the water body, and four new noise monitoring devices to detect and measure the noise level in the environment. Collect operational data, warning information, and alarm information of equipment and facilities for odor treatment, sewage treatment, boiler exhaust gas, and reclaimed water reuse, and achieve online monitoring of important pollutant emissions and key assessment indicators.

Operation status of pollutant treatment equipment and facilities Data Acquisition "1. Communication method: wireless, such as 5G/4G/wifi, etc;

2. Power supply mode: wired;

3. Working temperature: -20~60 ℃.

4. Interface: Supports 16 channels of information input.

5. Collect the power and status of the pollution control equipment control cabinet. 5 sets of dust removal equipment:Dry dust collectorDynamic sensing data such as internal temperature of ash hopper, pressure difference between inlet and outlet, and fault signals for air lock and ash unloading, as well as video monitoring data of dust collector, dust collection bin, dust production workshop and other parts

Others: Monitor the operation and networking status of the monitoring equipment. The installation location is within 5 electrical control cabinets of the sewage treatment plant equipment.

Wastewater monitoring (COD value)Sensor"1. Supports high-definition image output of no less than 4 million;

2. Communication method: wireless, such as 5G/4G/wifi, etc;

★ 3. COD accuracy not less than ± 5%, COD resolution 0.1mg/L;

4. The water quality probe is equipped with 3/4NPT pipe threads, making it easy to sink or install in pipelines and tanks;

5. The alarm linkage includes white light flashing alarm and sound alarm, and the alarm signal can be transmitted to the control center through the platform; Two sets of COD values
